DPA 4062 CORE+ Omni Mic, Extreme SPL, MicroLock
DPA 4062 CORE+ Omni Mic, Extreme SPL, MicroLock
Couldn't load pickup availability
DPA 4062 Omnidirectional, Low Sensitivity
The 4062 is available in two colors: black and beige.
The DPA 4062 is acoustically identical to the 4060, but the sensitivity is adjusted to match some of the more sensitive transmitters on the market. For a cordless microphone, choose from the adapter system or a hardwired connector.
Applications
The 4062 handles high sound pressure levels and is ideal for drums and brass.
Accessories
By changing the supplied grids (one high boost and one soft boost), you can acoustically modify the mic's response according to placement.
Wireless microphones
A wide range of connection adapters makes it possible to use DPA miniature microphones with all professional UHF, VHF, or digital wireless systems.
DPA has adapters for AKG, Audio Ltd., Audio-Technica, Beyerdynamic, Electro-Voice, Lectrosonics, Micron, Mipro, Pastega, Telex ProStar, Ramsa, Samson, Sennheiser, Shure, Sony, Toa, Vega, and other systems. Each adapter for your cordless microphone is guaranteed to perfectly mate to your system of choice.
Specifications
Offering great detail and resolution, the 4062 has a neutral sonic character and is very natural sounding. The 4062 has a very low noise floor, impressive sensitivity, and can handle high SPLs. The noise floor is 33 dB(A) re. 20 Pa and, if powered correctly, the microphone can handle sound pressure levels up to 154 dB SPL before clipping occurs.
Related microphones
The DPA 4061, 4062, and 4063 are acoustically identical but have different SPL handling or sensitivity.
Specifications for 4062 Omnidirectional, XLo-Sens
| Directional characteristics: | Omnidirectional |
|---|---|
| Principle of operation: | Pressure |
| Cartridge type: | Pre-polarized condenser element with vertical diaphragm |
| Frequency range, 2 dB: | Soft boost grid: 20 Hz - 20 kHz, 3 dB soft boost at 8 - 20 kHz. High boost grid: 20 Hz - 20 kHz, 10 dB boost at 12 kHz. |
| Sensitivity, nominal, 3 dB at 1 kHz: | 1 mV/Pa; -60 dB re. 1 V/Pa |
| Equivalent noise level A-weighted: | Typ. 33 dB(A) re. 20 Pa (max. 37 dB(A)) |
| Equiv. noise level ITU-R BS.468-4: | Typ. 45 dB (max. 49 dB) |
| S/N ratio, re. 1 kHz at 1 Pa (94 dB SPL): | 61 dB(A) |
| Total harmonic distortion (THD): | < 1 % THD up to 123 dB SPL peak; < 1 % THD up to 120 dB SPL RMS sine |
| Dynamic range: | Typ. 90 dB |
| Max. SPL, peak before clipping: | 154 dB |
| Output impedance: | 30 - 40 ohm |
| Cable drive capability: | Up to 300 m (984 ft) |
| Power supply: | For wireless systems: Min. 5 V - max. 50 V through DPA adapter. With DAD6001-BC/DAD6024/DAD4099: 48 V phantom power 4 V for full performance. |
| Connector: | MicroLock |
| Color: | Black, beige |
| Microphone weight: | 7.5 g (0.26 oz) incl. cable and MicroDot connector |
| Microphone diameter: | 5.4 mm (0.21 in) |
| Microphone length: | Max. 12.7 mm (0.5 in) |
| Cable length: | 1.8 m (5.9 ft) |
| Cable diameter: | 1.6 mm (0.06 in) |
| Polarity: | Positively increasing sound pressure produces positive going voltage on MicroDot pin |
| Operating temperature range: | -40 C to 45 C (-40 F to 113 F) |
| Relative Humidity (RH): | Up to 90% |
